Automatic swing door operation where overhead clearance is restricted or where a completely clean, uninterrupted transom line is architecturally required. Preferred for Toronto and GTA's most prestigious condominium developments and institutional projects.
| Mount Type | Bottom Load |
| Power Supply | 120VAC, 60Hz |
| Door Capacity | Upto 450 lbs of Weight |
| Control Board | Universal digital with visual display |
| DC Motor | 1/3 hp 24VDC permanent magnet |
| On Board Power Supply | 24 VDC 1.2 A |
| Position Switch (Magnet Reader) | Included — precise door position detection |
| Electric Lock Input | Fail Safe / Fail Secure |
| Open/Closed Status Output | Dry contact monitoring included |
| Fire Relay | Included |
| Finish Options | Anodized Clear Finish · Anodized Black Finish |
| Temp. Range | -30°C to +50°C |
| Origin | Vaughan, Ontario, Canada |
| Warranty | 1 year parts from date of invoice |
Width 4½" / Height 4½" · Standard width 39" for 36" door
Upto 450 lbs of Weight
1/3 hp 24VDC permanent magnet — long-lasting, trouble-free
Selectable - Yes
Reversible on Opening
24 VDC 1.2 A
Adjustable opening & closing speeds
Selectable closing force settings
Fail Safe / Fail Secure
Selectable before open & closing — prevents electric strike binding · Time and Force Adjustability
Set latching position and closing speed in latch zone
Set speed & position of back check for positive door control
Dry contact output for remote door status monitoring
Yes
Options available for non-standard applications
Interior / Exterior - Swing doors
Standard commercial specification — healthcare, institutions, and commercial applications.
Specified for luxury condominiums, hotels, and high-design commercial projects.
